Description

GRP2602p is an essential 2-line model designed with zero-touch provisioning for mass deployment and easy management. It features a sleek design and a suite of next-generation features including Wi-Fi support (GRP2602W), 5-way voice conferencing to maximize productivity, integrated PoE , full HD audio on both the speaker and handset to allow users to communicate with the utmost clarity, EHS support for Plantronics, Jabra, and Sennheiser headsets and multi-language support. The GRP series includes carrier-grade security features to provide enterprise-level security, including secure boot, dual firmware images and encrypted data storage. For cloud provisioning and centralized management, the GRP2602 is supported by Grandstream’s Device Management System (GDMS), which provides a centralized interface to configure, provision, manage and monitor deployment s of Grandstream endpoints. Built for the needs of on-site or remote desktop workers and designed for easy deployment by enterprises, service providers and other high-volume markets, the GRP2602 offers an easy-to-use and easy-to-deploy voice endpoint.

Supports 2 lines, and 4 SIP accounts
Supported by GDMS which provides a centralized interface to configure, provision, manage and monitor Grandstream devices
Electronic Hook Switch (EHS) support for Plantronics, Jabra, and Sennheiser headsets
Full-duplex speakerphone with HD audio to maximize audio quality and clarity
Equipped with noise shield technology to minimize background noise
The GRP2602P includes built-in PoE to power the device and give it a network connection
Supports 5-way audio conferencing for easy conference calls
Enterprise-level protection including secure boot, dual firmware images, and encrypted data storage
Swappable faceplate to allow for easy logo customization
GRP2602W includes built-in dual-band Wi-Fi support

Protocols/Standards
SIP RFC3261, TCP/IP/UDP, RTP/RTCP, RTCP-XR, HTTP/HTTPS, ARP, ICMP, DNS(A
record, SRV, NAPTR), DHCP, PPPoE, SSH, TFTP, NTP, STUN, SIMPLE, LLDP, LDAP, TR069, SNMP, 802.1x, TLS, SRTP, IPv6

Network Interfaces
– Dual switched auto-negotiation 10/100 Mbps Ethernet ports, integrated PoE
(GRP2602P only)
– Dual switched auto-negotiation 10/100/1000 Mbps Ethernet ports, integrated PoE
(GRP2602G only)
Wi-Fi GRP2602W, Integrated dual-band Wi-Fi 802.11 a/b/g/n/ac (2.4Ghz & 5Ghz)
Graphic Display 132 x 48 (2.41’’) backlit graphical LCD display

Feature Keys
2 line keys with dual-color LED and support for 4 SIP account, 4 XML programmable
context sensitive soft keys, 5 (navigation, menu) keys. 8 dedicated function keys
for: MESSAGE(with LED indicator), TRANSFER,HEADSET, MUTE, SEND/REDIAL,
SPEAKERPHONE, VOL+, VOLAuxiliary Port RJ9 headset jack (allowing EHS with Plantronics & Jabra &Sennheiser headsets), Support Grandstream UCM6510 IP PBX

Voice Codecs and Capabilities
Support for G.729A/B, G.711µ/a-law, G.726, G.722(wide-band), G.723,iLBC, OPUS,
in- band and out-of-band DTMF(in audio, RFC2833, SIP INFO), VAD, AEC, CNG, PLC,
AGC, AJB

Telephony Features
Hold, transfer, forward, 5-way conference, call park, call pickup, shared-callappearance(SCA)/bridged-line-appearance(BLA), downloadable phonebook(XML,
LDAP, up to 2000 items), call waiting, call log(up to 800 records), off-hook auto
dial, auto answer, click-to-dial, flexible dial plan, hot-desking, personalized music
ringtones and music on hold, server redundancy and fail-over
HD Audio Yes, HD handset and speakerphone with support for wideband audio
Base Stand Yes, 1 angle position available (45°), Wall Mountable (*wall mount sold separately)
QoS Layer 2 QoS (802.1Q, 802.1P) and Layer 3 (ToS, DiffServ, MPLS) QoS
Security
User and administrator level passwords, MD5 and MD5-sess based authentication,
256-bit AES encrypted configuration file, SRTP, TLS, 802.1x media access control,
secure boot
Multi-language English, German, Italian, French, Spanish, Portuguese, Russian, Croatian, Chinese,
Korean, Japanese and more
Upgrade/Provisioning Firmware upgrade via FTP/TFTP / HTTP / HTTPS, mass provisioning using GDMS/TR069 or AES encrypted XML configuration file
Power & Green Energy Efficiency Universal Power Supply Input 100-240VAC 50-60Hz; Output +5VDC, 600mA;PoE:
IEEE802.3af Class 1, 3.84W; IEEE802.3az (EEE) (GRP2602P/GRP2602G Only)
Temperature and Humidity
Operation: 0°C to 40°C
Storage: -10°C to 60°C
Humidity: 10% to 90% Non-condensing
Package Content GRP2602 phone, handset with cord, base stand, universal power supply (GRP2602 /
GRP2602W / GRP2602G only), network cable, Quick Installation Guide
Physical
Dimension: 208mm (L) x 180mm (W) x 63.4mm (H) (with handset)
Unit weight: 670g; Package weight: 880g (GRP2602 / GRP2602G / GRP2602W), 830g
(GRP2602P) GRP2602 / GRP2602P / GRP2602G

Compliance
FCC: Part 15 Class B; FCC Part 68 HAC;
CE: EN 55032; EN 55035; EN 61000-3-2; EN 61000-3-3; EN 62368-1;
RCM: AS/NZS CISPR32; AS/NZS 62368.1; AS/CA S004;
IC: ICES-003; CS-03;
GRP2602W Compliance
FCC: Part 15 Subpart B, Class B; Part 15 Subpart E, 15.407; Part 15 Subpart C, 15.247
CE: ETSI EN 301 893; ETSI EN 301 489-1/-17; ETSI EN 300 328; EN 62368-1; EN
62311; EN 55032; EN 55035; EN IEC 61000-3-2; EN 61000-3-3
IC: RSS-247 Issue 2; RSS-Gen Issue 5; ICES-003 Issue 7; CS-03, Part V
RCM: AS/NZS CISPR32; AS/NZS 4268; AS/NZS 2772.2; AS/NZS 62368.1; AS/CA S004
