Atcom D21

Description

Atcom D21 is a dual 100Mbps Ethernet port IP phone with 6 SIP accounts, 2 linekeys, and full-view backlit greyscale display. It is a cost-effective IP phone specially designed for office staff. It supports IPV6 & IPV4 and ATCOM cloud network management platform, with full “user, network, deployment, security” features, good IP PBX and network compatibility. It is suitable for enterprise unified communications and IP voice applications of operators. Its innovative multi-scene key mode, which can be used to expand up to 12 visible DSS keys, definitely improves the office productivity. It adds user-friendly help information to the LCD, whichcan reduce the user’s learning costs.

Atcom D21 Entry Level IP Phone

6 SIP accounts,L1 and L2 line support monochrome LED light
128*64 graphic lattice LCD
Multi-scene switch key
Navigation key
LED Phone status indicator
HD full range telephone receiver
High-power loudspeaker
Anti-interference microphone(handset and speakerphone)
Closed microphone cavity
Enter the guide interface. First: press the Menu key
Second: Enter the main menu interface, and press the second softkey
Last: Enter the guide interface and check the different guide step
D series new feature, add multi-scene key, enter the different multi-scene user mode, the most can switch 4 times and add 12 BLF programmable keys.
First: press the multi-scene key
Second: Enter the other softkey user mode

• Basic functions Atcom D21

  128*64 graphic character dot matrix with full view of backlight LCD, 6 SIP accounts, Call Forward, Call Transfer, Call Waiting, Hotline, Call Hold, Auto Answer, Redial, Mute, DND, Local 3-Way Conferencing, Speed Dial, Voice Mail, Local Phonebook (up to 1000 ), Direct IP call without SIP proxy, Black list, Dialed/Received/Missed/Forwarded call (400 total), Call Center Headsets mode

  Quick to use features

  Multi-scene feature, Guide user document, 13 programmable keys, One key to arrive menu, One key to read the phone information, Intelligent search for phonebook, Dial assistant

  IP PBX Features

  Intercom, Paging, Call pickup, Call park, Anonymous call, Anonymous call rejection, Hold on music Conference Call, Group pickup, DND&Call forward state synchronization, Call Recording

  Mult-language

  English, German, Italian, French, Spanish, Portuguese, Russian, Simplified or Traditional Chinese, Polish, Turkish, Hebrew

  Advanced Features

  LDAP, XML remote phonebook, Action URL, Active URI, CSTA, Multicast paging

  Audio Features

  5 ringtons (system ringtone or custom ringtone) article, 8 volume adjustable & Mute mode, Narrowband codec: G.711(a/μ), G.729A/B/AB, G.726, iLBC, OPUS, Wideband codec: G.722, L16, Support VAD, CNG, AEC, PLC, AJB, AGC, Full-duplex speakerphone with AEC

  Network Features

  IPv4&IPv6, VlAN, LLDP, CDP, OpenVPN, IEEE 802.1X, STUN NAT Traversal, RPORT. Support Qos(IEEE802.1Q/p VLAN tagging) and layer 3 QoS(ToS,DiffServ,MPLS). SIP connection mode: Proxy mode, Peer to Peer. Support DNS SRV (RFC3263). DTMF: In-band, RFC2833, SIP INFO. HTTP/HTTPS web server. LAN/PC: support bridge mode, Support auto negotiation, Package tracing via PC port. Package tracing export by web. Support DHCP Option12 host name and Option 60 Vendor Class ID. Support syslog

  WiFi Features

  Atcom D21 Security

  TLS, HTTPS, SRTP (RFC3711), Digest authentication using MD5/MD5-sess, AES encryption for configuration files, Phone lock, The administrator/user level access control

  Configuration

  Configurable through web interface/phone

  Batch deployment

  Service (RPS), TR069(Supported by special firmware), Import/Export CFG file via web, FTP/TFTP/HTTP/HTTPS, DHCP Option 66 or custom Option 128~254, PnP, Redirection Provisioning Generate multiple configuration files via tool, Periodic check and update

  Physical

  Power Interface: DC 5V-0.6A, PoE power supply: IEEE 802.3af Class 2 (D21) 2x RJ45 10/100M adaptive Ethernet ports, 1x RJ9 headphone jack, 1x RJ9 handset jack

  Temperature and Humidity

  Operating temperature: -10 ~ 50°C, Operating humidity: 10 ~ 90%

  Packaging information

  Qty/CTN: 10 PCS, G.W/CTN: 8.5 – 9KG, Giftbox size:230mm(L) *180mm(W) *90mm(H) Carton Meas: 460mm(L) * 236mm(W) *164mm(H)

  Certifications

  CE：EN62368、EN55032、 EN61000-3-2、EN61000-3-3、EN55035 FCC: Part15B

  Compatible PBX

  Read More

Why Choose Atcom D21

Personalized multi-scenario usage mode. Users can set the button mode according to the usage
requirements and habits, which sets a new efficiency benchmark for the entry-level phone.
More convenient operation by adding the usage help information.
Higher level voice quality by using sealed electroacoustic cavity and high-level electroacoustic devices.
Excellent hands-free voice quality with larger HD speaker.
Full view screen.
Anti-electromagnetic feature on handset and speaker, such as mobile phones.
OPUS codec supported.
OPEN VPN, LLDP and 802.1X supported.
Power protection measures to avoid machine damage caused by wrong operation.
Convenient deployment, support auto provision via WAN and LAN.
Perfectly compatible with leading IP PBX platform and third-party interface management supported.
