Description
| Entry-level high quality business IP Phone | |
A10W IP Phone is a multi-access network, easy to deploy and operate desktop office phone for enterprise users, which features excellent sound quality, elegant and smart design. It supports 1 SIP account, which combines economical, practical and excellent performance dual advantage in one. It is an entry-level IP Phone specially designed for business office, suitable for enterprise unified communications.
| | Top level voice quality | |
| | WIFI + cable connection enable flexible deployment | |
| | Dual core CPU is the guarantee of high quality IP phone | |
One core for instruction process and the other core for voice
decoding greatly improve the sound quality and make it possible
to run more complicated applications fluently.
Specification
| Basic functions 132 * 52 graphic character dot matrix with backlight LCD 1 SIP account Call Forward, Call Transfer, Call Waiting, Hotline, Call Hold, Auto Answer, Caller ID, Redial, Mute, DND Local 3-Way Conferencing, Speed Dial, Voice Mail Phone Book (400) Direct IP call without SIP proxy Black list, white list, Dialed/received/missed/Forward call (400 in total) Call Center Headsets mode | IP PBX features Intercom, Paging, Call pickup, Call park Anonymous call, Anonymous call rejection Hold on music, Conference Call Group Listening, Group pickup DND&Call forward state synchronization Call Recording | Advanced features LDAP Microsoft active directory server XML remote phonebook TR069 Action URL | Audio Features 10( own ring tone+custom ring tone) article 8 volume adjustable + Mute mode Narrowband codec: G.711(A/μ), G.729A/B/AB, G.726, iLBC Wideband codec: G.722, L16 Support VAD, CNG, AEC, PLC, AJB, AGC Full-duplex speakerphone with AEC |
| Network features LAN / PC: support bridging mode Openvpn SIP connection mode: Proxy mode, and P2P mode Support DNS SRV (RFC3263) NAT transverse: STUN mode DTMF: In-band, RFC2833, SIP INFO Support QoS IPv4&IPv6 HTTP / HTTPS web server Span to PC Package tracing export System log Physical characteristics | WiFi feature (only models A10W) Support IEEE 802.11b/g/n Enhanced support for IEEE 802.11e QoS IEEE802.11i (WPA, WPA2) Use of the environment | SafetySupport VLAN, LLDP, IEEE802.1X Support TLS Support HTTPS SRTP (RFC3711) Digest authentication using MD5/MD5-sess AES encryption for configuration file Support phone lock, the administrator / user level access control Package | Configuration PnP configuration: based on the server implementation Redirection and Provisioning Service(RPS) Manual configuration:Web, Keypad Batch deployment: HTTP/FTP/TFTP/RPS/DHCP Option 66 |
